uClamp0502P
PROTECTION PRODUCTS
Marking Code
Ordering Information
P a r t N u m b e r
W o r k i n g
V o l t a g e
Q t y p e r
R e e l
R e e l
S i z e
05
u C l a m p 0 5 0 2 P . T C T 5 V 3 , 0 0 0 7 I n c h
Notes:
1) This is a lead-free, RoHS/WEEE compliant product
MicroClamp, uClamp and μ Clamp are marks of Semtech
Corporation
Tape and Reel Specification
Pin 1 Location
User Direction of feed
Device Orientation in Tape
A 0
0 . 6 9 + / - 0 . 1 0 m m
B 0
1 . 1 9 + / - 0 . 1 0 m m
K 0
0 . 6 6 + / - 0 . 1 0 m m
T a p e
W i d t h
8 m m
B , ( M a x )
4 . 2 m m
( . 1 6 5 )
D
1 . 5 + 0 . 1 m m
- 0 . 0 m m
( 0 . 5 9 + . 0 0 5
- . 0 0 0 )
D 1
0 . 4 m m
± 0 . 2 5
( . 0 3 1 )
E
1 . 7 5 0 ± . 1 0
m m
( . 0 6 9 ± . 0 0 4 )
F
3 . 5 ± 0 . 0 5
m m
( . 1 3 8 ± . 0 0 2 )
P
4 . 0 ± 0 . 1 0
m m
( . 1 5 7 ± . 0 0 -
4 )
P 0
4 . 0 ± 0 . 1
m m
( . 1 5 7 ± . 0 0 -
4 )
P 2
2 . 0 ± 0 . 0 5
m m
( . 0 7 9 ± . 0 0 2 )
T
0 . 2 5 4 ± 0 . 0 2
m m ( . 0 1 6 )
W
8 . 0 m m
+ 0 . 3 m m
- 0 . 1 m m
( . 3 1 2 ± . 0 1 2 )
Contact Information
Semtech Corporation
Protection Products Division
200 Flynn Rd., Camarillo, CA 93012
Phone: (805)498-2111 FAX (805)498-3804
? 2008 Semtech Corp.
7
www.semtech.com
